Characteristics of the editor

1. Highly effective removal of water, oil mist, solid particles, 100% removal of 0.01 m or more particles, oil mist concentration control at 0.01 PPM /wt;

2. Reasonable structure, small size and light weight;

3. Optional plastic shell and aluminum shell with protective cover;

4. Three-stage purification treatment, long service life.

Microporous filter element

Type editor

Q precision filter

Precision filter
Precision filter
General scope: general reciprocating air compressor pre - filter material, multi - layer glass fiber filter
Filter impurities: 5MICRON
Oil content: 5PPM
Maximum pressure: 16KG/CM
The highest temperature: 65 ℃
General differential pressure: 0.2kg /CM
Maximum differential pressure: 0.7kg /CM
Function: filter a large amount of oil and gas in the compressed gas to within 5PPM and remove impurity particles to 5MICRON

P level precision filter

General scope: general screw air compressor pre - filtration
Material: multilayer glass fiber filter
Filter impurities: 1MICRON
Filter oil content: 0.5PPM
Maximum pressure: 16KG/CM
The highest temperature: 65 ℃
General differential pressure: 0.17KG/CM
Maximum differential pressure: 0.7kg /CM
Function: filter oil and gas in compressed air to 0.5ppm to remove impurity particles below 1MICRON

S-class precision filter

General scope: general air compressor rear filter

Material: multilayer glass fiber filter
Filter impurity: 0.01MICRON
Filter oil content: 0.01PPM
Maximum pressure: 16KG/CM
The highest temperature: 65 ℃
General differential pressure: 0.275KG/CM
Maximum differential pressure: 0.7kg /CM
Function: accurately filter trace oil and gas in the compressed air to 0.01PPM, and meanwhile filter impurity particles in the air to 0.01MICRON to achieve high quality compressed air without oil standard
Class C precision filter
General use: for filter with high precision
Material: active carbon filter
Filter impurity: 0.03MICRON
Filter oil content: 0.003PPM
Maximum pressure: 16KG/CM
The highest temperature: 65 ℃
General differential pressure: 0.75KG/CM
Maximum differential pressure: 0.7kg /CM
Function: it is used to filter ozone in compressed air, very fine oil and gas and ultrafine particles
In order to achieve high precision filtration quality, the precision filter adopts multi-layer filter materials, including fiber layer of borosilicate, glass fiber layer, activated carbon fiber layer, multi-layer non-woven cloth layer and stainless steel mesh layer.Only in this way can we achieve high quality air without oil and impurities.
Supplement:
C the main passing filter removes large amounts of liquid and solids over 3 m to a minimum residual oil content of only 5ppm with a small amount of water, dust and oil mist.For air compressor, after rear cooler, before other filters, for general protection;It is used as a pretreatment device before cooling and drying machine.
Air line filter can remove liquid and solid particles as small as 1 m, up to a minimum residual oil content of only 0.5 PPM, with trace water, dust and oil mist.Used for pre-treatment before a-level filter;Further improve the air quality after the coolers and dryers.
A super high efficiency oil removal filter can remove liquid and solid particles as small as 0.01 m, up to A minimum residual oil content of 0.001 PPM, almost all water, dust and oil are removed.Used for protection before class H filter and dryer, after cold dryer, ensure no oil in the air.
H activated carbon mist filter can filter small to 0.01 m oil mist and hydrocarbons, to the minimum residual oil content of only 0.003 PPM, no water, dust and oil, odorless and tasteless.It ACTS as a final filter for units that must use high quality air, such as the food industry, respiration, sterile packaging, etc
